DC Volts |
Ranges 200 mV, 2 V, 20 V, 200
V, 1000V |
Resolution 0.1 mV, 1 mV, 10
mV, 100 mV, 1 V |
Accuracy ±(0.8 % rdg + 1
dgts) |
Input Impedance 10 MΩ |
Overload Protection 1000 VDC
or 750 VACrms* |
AC Volts (50 Hz-500 Hz) |
True RMS Applies |
Ranges 200 mV, 2 V, 20 V, 200
V, 750V |
Resolution 0.1 mV, 1 mV, 10
mV, 100 mV, 1 V |
Accuracy 200 mV & 20 V
ranges: ±(1.5 % rdg + 8 dgts) |
200 V & 750 V ranges:
±(2.0 % rdg + 8 dgts) |
Crest Factor <3 |
Input Impedance 10 MΩ |
Overload Protection 1000 VDC
or 750 VACrms* |
DC Current |
Ranges 20 mA, 200 mA, 10 A |
Resolution 10 uA, 100 uA, 10
mA |
|
|
