DC Volts |
Ranges 400 mV, 4 V, 40 V, 400 V, 1000 V |
Resolution 0.01 mV, 1 mV, 10 mV, 100 mV,
1 V |
Accuracy 400 mV range: ±(0.15 % rdg + 10
dgts) |
4 V to 1000 V ranges: ±(0.1 % rdg + 5
dgts) |
Input Impedance 400 mV: >3 MΩ; 4 V to
1000 V: 2.3 MΩ |
Overload Protection 1000 VDC or 750
VACrms |
AC Volts (45 Hz-1 kHz) |
True RMS Applies |
Ranges 400 mv, 4 V, 40 V, 400
V, 750 V |
Resolution 0.01 mV, 1 mV, 10
mV, 100 mV, 1 V |
Accuracy 400 mV to 400 V
ranges: ±(1.2% rdg + 20dgts) 45 ~ 60 Hz |
4 V range: ±(1.5% rdg + 20
dgts) 60 ~ 500 Hz |
40 V to 400 V ranges: ±(1.5%
rdg + 20dgts) 60 ~ 1 kHz |
750 V range: ±(2.0% rdg + 20
dgts) 45 ~ 500 Hz |
AC + DC Volts (45 Hz-1 kHz) |
True RMS Applies |
Ranges 400 mv, 4 V, 40 V, 400
V, 750 V |
Resolution 0.01 mV, 1 mV, 10
mV, 100 mV, 1 V |
Accuracy 400 mV to 400 V
ranges: ±(1.5% rdg + 20dgts) 45 ~ 60 Hz |
4 V range: ±(2.0% rdg + 20
dgts) 60 ~ 500 Hz |
40 V to 400 V ranges: ±(2.0%
rdg + 20dgts) 60 ~ 1 kHz |
750 V range: ±(2.0% rdg + 20
dgts) 45 ~ 500 Hz |
Crest Factor <3 |
AC coupled True RMS Specified
from 10% to 100% of range |
Input Impedance 400 mV: >3
MΩ; 4 V to 750 V: 2.3 MΩ |
Overload Protection 1000 VDC
or 750 VACrms |
DC Current |
Ranges 40 mA, 400 mA, 10 A |
